TrailMaster Mid XRX, 4-Stroke, Air Cooled, Single Cylinder GoKart, Carb Approved - Available in Crate
Get going with the new TrailMaster Mid-XRX Go Kart Available in Crate featuring a dependable overhead valve engine and a cutting-edge CVT drivetrain for awesome low-end torque! The XRX is the perfect size for intermediate riders but big enough to pack a punch with speeds up to 31 mph!
The fully integrated frame includes side rails and an enclosed belly pan for better protection on the trails, plus an upper brush guard cage complete with canopy for those long days riding in the sun. And the full front and rear coil-over double oil dampened shock suspension gives a smooth, even ride for sure-footed traction on any terrain. The XRX also features keyed ignition electric start, head and tail lights, a horn and dual sport seats with safety belts, rack-and-pinion steering and a fully automatic transmission for safe, simple operation. This is what fun feels like!
This vehicle is also available in a CARB approved model that meets or exceeds guidelines established by the California Air Resources Board and can be sold in the state of California. CARB approved vehicles have modified engines and exhaust systems designed to reduce emissions.
Technical Specs
Parts breakdown set up manuel
Specifications
- Engine Type: 196cc, 4-Stroke, Air Cooled, Single Cylinder
- Max horsepower: 6.3hp/3600rpm
- Max torque: 9.6lb ft/3600rpm
- Fuel Requirement: unleaded
- Start Type: Electric start with pull start backup
- Transmission: Fully Automatic CVT, Chain/Dual Wheel Drive
- Battery: 12V 9Ah
- Ignition: CDI
- Front Brake: None
- Rear Brake: Hydraulic Disc
- Suspension: Dual A-arm Front / Swing arm Rear with Double Oil Damped Shock
- Front Tires: 16 x 6-8
- Rear Tires: 16 x 7-8
- Max speed: 31 mph approximate
- Climbing: 12 degrees
- Horn
- Dual LED headlights
- Seat belts
- Speed Limiter
- Fuel Capacity: 1 gal.
- Wheelbase: 48.4 inches
- Gross weight: 400 lbs.
- Net weight: 330 lbs.
- Max Loading: 400 lbs.
- Overall Size (inches): 66.93*43.31*25.98
- Ground Clearance: 2.8 inches
- Height to seat: 10.2 inches
- Pedal to seat back: Adjustable from 31.5 to 37 inches
- CARB Approved models available
- Several colors
