New Coolster ATV-3200U 175CC Fully Automatic Full Sized Utility ATV New model, upgrade bigger engine from 3150DX4
The Coolster ATV-3200U 175CC Utility ATV is a powerful, full-sized utility ATV designed for off-road enthusiasts. Featuring a 170cc, single-cylinder, 4-stroke, air-cooled engine, this model offers enhanced performance with a CVT automatic transmission and chain-driven rear-wheel drive. Equipped with front hub brakes and a rear hydraulic disc brake, it ensures reliable stopping power. With rugged 23x7-10 front and 22x10-10 rear tires, this ATV is built for tackling tough terrain. The electric start with CDI ignition provides easy operation, while the durable construction makes it a dependable choice for both recreational and work use.
Please read the owner’s manual and all on-product warnings. ATVs can be hazardous to operate. For operator’s safety, always wear a helmet, eye protection, and protective gear. Never carry a passenger. Never ride under the influence of drugs nor alcohol. Never ride on public roads nor pavement. Be extra careful on difficult terrain. Never allow a child under the age of 16 to operate an ATV without adult supervision. It is strongly recommended that all ATV riders take a training course. For more information, contact your local dealer or call 1+ (888) 521-0527
Maxtrade LLC. 2022
TECHNICAL SPECS
| Model Number: | ATV-3175U |
| Engine Type: | Single cylinder, 4-stroke, air-cooled |
| Displacement: | 170cc |
| Max Torque: | 9.2.N.m/6,000r/min (N.m/r/min) |
| Max Power: | 6.5kW/8,000r/min (N.m/r/min) |
| Bore Stroke: | 57.4 x 57.8mm |
| Ignition: | CDI |
| Starting System: | Electric |
| Battery: | 12V, 9Ah |
| Clutch: | CVT Automatic |
| Transmission: | Chain, rear wheel drive |
| Brakes Front/Rear: | Hub/hydraulic disc |
| Tires Front/Rear: | 23 x 7 – 10 / 22 x 10 – 10 |
| Fuel Capacity: | 5.6L |
| Weight (G.W./N.W): | 183 kg/164 kg - 403 lbs/361 lbs |
| Wheelbase: | 1215mm |
| Dimensions: | (mm) 1524x812.8x762 / (Inches) 60x32x30 |
| Height to Seat: | 620mm |
| Min. Ground Clearance: | 165mm |
